WP-571 Water Pump – Ford 5.0L / 4.2L V8 Fitment
type: Unknown Type
Vendor: CorvairFarmer
Description:
WP-571 is a cast iron mechanical water pump used on 1981–1986 Ford 4.2L and 5.0L V8 engines, including Mustang, LTD, Thunderbird, and F-Series trucks.Â
📊 Specifications & Dimensions
| Attribute | Value |
|---|---|
| Part Number | WP-571 / PW571 / CP4014 |
| Type | Mechanical Water Pump |
| Rotation Direction | Standard (clockwise) |
| Impeller Material | Steel |
| Impeller Diameter | 3.94 inches |
| Hub Height | 5.70 inches (144 mm) |
| Drive Style | Belt |
| Housing Material | Cast Iron |
| New or Remanufactured | New |
| Electric or Mechanical | Mechanical |
| Country of Origin | USA / China (varies) |
| Shipping Weight | ~8.0 lbs |
| Box Dimensions | Approx. 8.4" × 23.4" × 12.6" |
🚗 Verified Fitment Chart
| Make | Model | Engine | Years |
|---|---|---|---|
| Ford | Mustang | 5.0L V8 | 1982–1985 |
| Ford | LTD | 5.0L V8 | 1981–1986 |
| Ford | Thunderbird | 5.0L V8 | 1981–1986 |
| Ford | F-150 / F-250 | 4.2L / 5.0L | 1981–1986 |
| Mercury | Cougar | 5.0L V8 | 1981–1986 |
| Lincoln | Continental | 5.0L V8 | 1982–1985 |
Cross-references:
-
Motorcraft PW571
-
Murray CP4014
-
Bosch 98057
-
ACDelco 251-326, 252-607
-
Airtex AW4014
-
Gates 43150
-
Dayco DP1455
-
Cardone 5521121
