GM R43CXLS (5613940) Spark Plug - SOLD EACH
type: Unknown Type
Vendor: CorvairFarmer
Description:
Specifications
| Specification | Detail |
|---|---|
| Manufacturer | ACDelco |
| GM Part Number | 5613940 |
| ACDelco Part Number | R43CXLS |
| UPC | 36666238044 |
| Thread Size | 14 mm |
| Thread Reach | 19.05 mm (0.750″) |
| Seat Type | Gasket |
| Heat Range | 3 |
| Preset Gap | 0.033″ (0.86 mm) |
| Core Material | Copper |
| Center Electrode Tip | Nickel Alloy |
| Insulator Nose | Ribbed |
| Resistor Value (Ω) | 2,000–20,000 |
| Insulator Height | 56.49 mm (2.224″) |
| Hex Size | 21 mm (13/16″) |
| Terminal Type | Non-Removable Nut |
by Make, Model & Years
| Make | Model | Year Range | Engine Displacement (CID/L) |
|---|---|---|---|
| Chevrolet | Camaro (base/L82/RS) | 1977–1987 | 305 ci (5.0 L) V8 |
| Chevrolet | Camaro Z28/IROC-Z | 1982–1992 | 305 ci (5.0 L); 350 ci (5.7 L) V8 |
| Chevrolet | Corvette (C3/C4) | 1978–1985 | 350 ci (5.7 L) V8 |
| Chevrolet | C/K Pickup (C10/C20) | 1977–1987 | 305 ci (5.0 L); 350 ci (5.7 L) V8 |
| Chevrolet | Caprice/Impala | 1977–1990 | 305 ci (5.0 L); 350 ci (5.7 L) V8 |
| Pontiac | Firebird/Base/Formula | 1977–1987 | 305 ci (5.0 L) V8 |
| Pontiac | Trans Am | 1979–1992 | 305 ci (5.0 L); 350 ci (5.7 L) V8 |
| Pontiac | Grand Prix | 1977–1987 | 301 ci (4.9 L); 350 ci (5.7 L) V8 |
| Buick | Century | 1977–1987 | 305 ci (5.0 L) V8 |
| Buick | Regal/Grand National | 1978–1987 | 231 ci (3.8 L) V6; 301 ci (4.9 L) V8 |
| Oldsmobile | Cutlass/Ciera | 1977–1987 | 305 ci (5.0 L); 350 ci (5.7 L) V8 |
| GMC | Jimmy/Sierra Pickup | 1977–1987 | 305 ci (5.0 L); 350 ci (5.7 L) V8 |
Cross-Reference Numbers
| Brand | Part Number |
|---|---|
| Accel | 0494 |
| Autolite | 3206 |
| Beck Arnley | 176-5082 |
| Bosch | WR6DC |
| Champion | 404 |
| Denso | W16EPR-U |
| NGK | BP4ES |
| Motorcraft | AGS32C |
| Mopar | 4091713 |
| GM | 5612425 |
