FEDERATED LF230F — SPIN‑ON OIL FILTER — NOS — PH8A / PF13 / FL‑1A CROSS
type: Unknown Type
Vendor: CorvairFarmer
Description:
🧰 FEDERATED LF230F — SPECIFICATIONS & CROSS‑REFERENCE CHART
🔧 Technical Specifications
| Attribute | Details |
|---|---|
| Part Number | LF230F |
| Type | Spin‑On Oil Filter |
| Thread Size | 3/4"-16 |
| Canister Length | ~4.8 in |
| Diameter | ~3.7 in |
| Gasket Profile | Standard PH8A / PF13 family |
| Anti‑Drainback Valve | Yes |
| Bypass Valve | Yes |
| Filter Media | Cellulose |
| Micron Rating | ~20–25 micron |
| Construction | Heavy‑gauge steel, full‑flow design |
| Status | NOS (discontinued) |
🔁 Cross‑Reference Equivalents
| Brand | Equivalent Part Number |
|---|---|
| FRAM | PH8A |
| ACDelco | PF13 / PF221 / PF222 |
| Motorcraft | FL‑1A |
| Purolator | PER‑1 / PER‑14 |
| WIX | 51515 |
| Group 7 | V4484 |
| Luber‑Finer / Champ | PH8A equivalents |
| NAPA / Carquest | 1515 / 85515 |
🚗 Common Applications
-
Ford: 289, 302, 351W, 351C, 390, 460
-
Chrysler: Slant‑6, 318, 340, 360, 383, 440
-
AMC/Jeep: 232, 258, 304, 360, 401
-
GM: Marine and industrial engines using PH8A‑style filters
-
Industrial: Generators, compressors, tractors, marine engines
