FEDERATED LF107F — SPIN‑ON OIL FILTER — NOS — PH16 / PH3600 / PF2191 CROSS
type: Unknown Type
Vendor: CorvairFarmer
Description:
Federated LF107F — Specifications, Cross‑Reference & Sales‑Ready Copy
The LF107F is the short‑can Federated oil filter on your shelf — the counterpart to the long PF13/PH8A family. It matches the PH16/PH3600 size class and is widely used on Chrysler, Jeep, Mitsubishi, and small‑block applications.
🔧 Technical Specifications
| Attribute | Details |
|---|---|
| Part Number | LF107F |
| Filter Type | Spin‑On, Full‑Flow |
| Thread Size | 3/4"-16 |
| Length | ~3.8 in (short‑can format) |
| Diameter | ~3.7 in |
| Gasket Profile | PH16 / PH3600 family |
| Anti‑Drainback Valve | Yes |
| Bypass Valve | Yes |
| Media | Cellulose |
| Micron Rating | ~20–25 micron (typical for this family) |
| Status | NOS (discontinued retail line) |
🔁 Cross‑Reference Equivalents
| Brand | Equivalent Number |
|---|---|
| FRAM | PH16 / PH3600 / PH43 |
| ACDelco | PF13 / PF2191 / PFL400A |
| WIX | 51348 (short) |
| Purolator | L10241 |
| Motorcraft | FL‑300 |
| Carquest | 85085 / 85085HD |
| Hastings | LF107 |
| Luber‑Finer | PH253 / PH16 |
| Chrysler OEM | 04781452 / 05281090 / 5281090 |
| GM | 25162816 |
🚗 Common Applications
-
Chrysler / Dodge / Plymouth 2.2L, 2.5L, 3.0L V6, small‑block applications using PH16‑type filters
-
Jeep / AMC 2.5L I4, select 4.0L years
-
Mitsubishi 2.6L, 3.0L V6 (Chrysler‑sourced platforms)
-
Ford Small industrial engines
-
Universal Compressors, generators, small equipment using PH16/PH3600‑type filters
