TRU-TECH D5040 Brake Rotor – GM F-Body Front Disc Fitment
type: Unknown Type
Vendor: CorvairFarmer
Description:
TRU-TECH D5040 is a front brake rotor used on 1982–1992 Chevrolet Camaro, Pontiac Firebird, and related GM F-body platforms with standard disc brakes.Â
📊 Specifications & Dimensions
| Attribute | Value |
|---|---|
| Part Number | TRU-TECH D5040 |
| Type | Front Vented Brake Rotor |
| Nominal Diameter | 10.50 inches |
| Nominal Thickness | 1.02 inches |
| Discard Thickness | 0.89 inches |
| Bolt Pattern | 5 x 4.75" |
| Center Bore | ~2.78 inches |
| Overall Height | ~2.75 inches |
| Material | Cast Iron |
| Finish | Machined or Zinc Coated |
| Country of Origin | China |
| Shipping Weight | ~18–20 lbs |
| Box Dimensions | Approx. 12" × 12" × 3" |
🚗 Verified Fitment Chart
| Make | Model | Years | Position |
|---|---|---|---|
| Chevrolet | Camaro | 1982–1992 | Front |
| Pontiac | Firebird | 1982–1992 | Front |
| Pontiac | Trans Am | 1982–1992 | Front |
Cross-references:
-
Raybestos 5040 / 5040R
-
Wagner BD5040
-
Bendix 141195
-
ACDelco 18A5040
-
AIMCO 5440
-
Parts Master 60545
-
Carquest 5440
