TRU-TECH D5036 Brake Rotor – GM Compact Truck/SUV Front Disc Fitment
type: Unknown Type
Vendor: CorvairFarmer
Description:
Specifications & Dimensions
| Attribute | Value |
|---|---|
| Part Number | TRU-TECH D5036 |
| Type | Front Vented Brake Rotor |
| Nominal Diameter | 10.50 inches |
| Nominal Thickness | 1.02 inches |
| Discard Thickness | 0.89 inches |
| Bolt Pattern | 5 x 4.75" |
| Center Bore | ~2.79 inches |
| Overall Height | ~2.75 inches |
| Material | Cast Iron |
| Finish | Machined or Zinc Coated |
| Country of Origin | China |
| Shipping Weight | ~18–20 lbs |
| Box Dimensions | Approx. 12" × 12" × 3" |
🚗 Verified Fitment Chart
| Make | Model | Years | Position |
|---|---|---|---|
| Chevrolet | S-10 Pickup | 1983–1997 | Front |
| Chevrolet | S-10 Blazer | 1983–1994 | Front |
| Chevrolet | Blazer | 1995–1997 | Front |
| GMC | S-15 Pickup | 1983–1990 | Front |
| GMC | Sonoma | 1991–1997 | Front |
| GMC | Jimmy | 1992–1997 | Front |
| GMC | Syclone | 1991 | Front |
| GMC | Typhoon | 1992–1993 | Front |
| Oldsmobile | Bravada | 1991–1996 | Front |
| Buick | Riviera | 1979–1985 | Front |
| Cadillac | Eldorado, Seville | 1979–1985 | Front |
| Oldsmobile | Toronado | 1979–1985 | Front |
Cross-references:
-
Raybestos 5036 / 5036R
-
Wagner BD8126
-
Bendix PRT8126
-
ACDelco 18A8126
-
Autospecialty AR8126
