Raybestos 6865 Brake Rotor & Hub – Ford/Mazda Front Disc Assembly
type: Unknown Type
Vendor: CorvairFarmer
Description:
Specifications & Dimensions
| Attribute | Value |
|---|---|
| Part Number | Raybestos 6865 / 6865R |
| Type | Front Brake Rotor & Hub Assy |
| Rotor Diameter | ~10.28 inches |
| Nominal Thickness | 0.875 inches (22.2 mm) |
| Discard Thickness | 0.81 inches (20.55 mm) |
| Bolt Pattern | 5 x 4.5" (114.3 mm) |
| Bolt Hole Diameter | 0.54 inches (13.7 mm) |
| Stud/Lug Hole Quantity | 5 |
| Overall Height | 4.134 inches (105 mm) |
| ABS Tone Ring | Not Included |
| Material | G3000 Cast Iron |
| Finish | Non-directional ground |
| Shipping Weight | ~20–22 lbs |
| Country of Origin | China |
🚗 Verified Fitment Chart
| Make | Model | Years | Position |
|---|---|---|---|
| Ford | Ranger | 1983–1994 | Front |
| Ford | Bronco II | 1984–1990 | Front |
| Ford | Aerostar | 1986–1991 | Front |
| Mazda | B2300/B3000/B4000 | 1994 | Front |
OEM Cross-references:
-
Ford E3TZ1102A, F47Z1102A
-
Mazda ZZM033251, ZZMO33251
-
Raybestos 6865R
-
Wagner BD60239
