Moog ES2513LR Outer Tie Rod End
type: Unknown Type
Vendor: CorvairFarmer
Description:
🔧 Moog ES2513LR — Technical Overview
| Attribute | Spec |
|---|---|
| Type | Outer Tie Rod End (Left) |
| Thread Size (End 1) | M14 × 1.5 (Clockwise) |
| Thread Size (End 2) | M12 × 1.3 |
| Length | 4.3 inches (Stud center to end) |
| End Type | Female × Female |
| Boot Material | Polychloroprene (sealed) |
| Construction | Forged alloy steel, heat-treated |
| Grease Grooves | Yes – ensures full lubrication flow |
🚗 Verified Vehicle Fitment
| Make | Model | Years | Position |
|---|---|---|---|
| Ford | Taurus | 1986–1995 | Outer Left |
| Mercury | Sable | 1986–1995 | Outer Left |
| Lincoln | Continental | 1988–1994 | Outer Left |
🔍 Verified via Moog catalog and OEM part match. This part is not universal and should not be used outside these applications without dimensional verification.
🔁 Cross-Reference Numbers
| Brand | Part Number |
|---|---|
| Ford OEM | E6DZ-3A130A, F0DZ-3A130A, F2DZ-3A130A |
| ACDelco | 45A0365, 46A0365A |
| Mevotech | MES2513RL |
| Raybestos | 401-1365B |
| TRW | ES2513R |
| Perfect Circle | 269-2667 |
| MAS Industries | T2513 |
| McQuay-Norris | ES2513R |
| Duralast | ES2513R |
| Dorman | 534-400 |
| Centric | 612.61127, 613.61127 |
| Autospecialty | 03-81002, 0381002E |
| Coni-Seal | XES2513RL |
